Spectra GL622N-BCC Dual Grade Laser with NiMH
Spectra Precision Laser GL622N-BCC Description
The Spectra Precision GL622N is a self-leveling, dual-grade construction laser with long-range operation up to 2,600 feet. With an intuitive keypad and graphic LCD, this rotary laser features automatic axis alignment and offers PlaneLok and grade matching capabilities for highly-accurate results. Capable of tilting on both axes for precise measurement of slopes, the GL622N laser can be used in a wide variety of outdoor grading and excavating. Automatic axes alignments can be accomplished by positioning the laser receiver at the direction hub in a range of ±40° at the desired laser axis. This allows construction professionals to easily perform axis alignments for grade work applications such as sports fields, parking lots, tennis courts, driveways, or any irregular field with non-perpendicular grade profiles.
Spectra Precision Laser GL622N-BCC Includes
- (1) GL622N Dual Grade Laser
- (1) Q104781 Worldwide Charger
- (1) Q104667 NiMH Battery pack
- (1) 5289-0670 Carrying Case
- (1) Operating Manual
Spectra Precision Laser GL622N-BCC Features
- Up to 2,600 feet operating range with laser receiver
- ±1/16 inch accuracy at 100 feet
- Self-leveling within ±14 degrees
- Dual grade to ±25% in both axes
- Automatic axis alignment
- Grade matching measures and displays the existing grade
- PlaneLok automatically locks on the laser beam
- Scan mode with five preset sizes and variable adjustment
- Mask mode for using multiple lasers on site
- Electronic leveling vibration filter
- Automatic temperature compensation
- Optional radio remote control
- Ideal for machine control applications
- 5/8-11 tripod thread
- Up to 40-hour battery life
- Water resistant and dustproof to IP-67
- Withstands a 3 feet drop onto concrete
- Graphic LCD display and keypad
