Southwire 41171N Voltage/Continuity/Phase Rotation Tester
Southwire 41171N Description
Voltage/Continuity/Phase Rotation Tester 41170S
This versatile tester features a built-in flashlight, single probe AC voltage check, phase rotation on three phase circuits, and automatic indication of continuity and AC and DC voltage up to 600 volts in 8 steps.
Southwire 41171N Includes
- (1) 41171N Tester with integrated test leads
- (2) AAA batteries
Southwire 41171N Features
- 8 step LED indication of AC voltage up to 600 V and DC voltage up to 400V
- One Probe live voltage check
- Indicates phase rotation on three phase circuits
- Audible and visual continuity test
- Built-in LED flashlight
- CAT III 600V, UL Listed
Southwire 41171N Specifications
| AC Voltage Range | 24,48,120,208,240,277,480,600V AC |
| DC Voltage Range | 6,12,24,36,48,110,220,400V DC |
| Tolerances | -30% to 0% of indication |
| Single Pole Voltage Test | 100 to 480V AC |
| Rotary Field Indication | 100 to 400V AC |
| AC Operating Frequency | 50/60Hz |
| Continuity Test | beeper will sound if the resistance is under 300k? |
| Overload Protection | 600V AC/DC |
| Dimensions | 9.5 x 3.1 x 1.5 in. (241 x 79 x 38mm) |
| Weight | 0.6 lbs. (272g) |
