Simpson Strong-Tie ZN25112B (1/4″ x 1-1/2″) Zinc Nailon Pin-Drive Anchor (1000 Pack)
Simpson Strong-Tie ZN25112B Description
Zinc Nailon anchors are low-cost, mushroom head anchors designed for static load applications. They are easily installed by hammering the pin through the anchor, expanding its body to secure it in place.
Simpson Strong-Tie ZN25112B Includes
- (1000) Zinc Nailon Pin-Drive Anchor
Simpson Strong-Tie ZN25112B Features
- Low-cost mushroom head design
- Tamper-resistant pin and head configuration
- Easily installed with a hammer
- Expands to hold securely in place
Simpson Strong-Tie ZN25112B Applications
- Concrete: Securely anchors into concrete surfaces
- CMU: Suitable for use in concrete masonry units
- Brick: Effective for anchoring into brick materials
- Static load applications: Designed for non-overhead static loads
Simpson Strong-Tie ZN25112B Installation Overview
- Drill a hole in the base material using a carbide drill bit of the same diameter as the anchor.
- Blow the hole clean using compressed air or drill deeper to accommodate dust.
- Position the fixture and insert the Nailon anchor.
- Tap the anchor with a hammer until flush with the fixture.
- Drive the pin until it is flush with the top of the head.
Simpson Strong-Tie ZN25112B Specifications
| Diameter | 1/4″ |
| Finish | Zinc Plated |
| Length | 1-1/2″ |
| Material | Carbon Steel |
| Drill bit size | 1/4″ |
| Quantity | 1000 |
NOTE: This product is not for use in overhead applications.
