Simpson Strong-Tie TNT18114TFC8 Titen Turbo (3/16″ x 1-1/4″) Flat-Head Concrete and Masonry Screw, Blue (8 Pack)
Simpson Strong-Tie TNT18114TFC8 Description
The Simpson Strong-Tie Titen Turbo screw anchor is a heavy-duty fastener designed for concrete and masonry applications, featuring a patented torque reduction channel for smooth driving and superior holding power.
Simpson Strong-Tie TNT18114TFC8 Includes
- (8) Titen Turbo Screw Anchors
Simpson Strong-Tie TNT18114TFC8 Features
- Patented Torque Reduction Channel for reduced binding
- Available in multiple coated versions
- Hex head or 6-lobe-drive countersunk flat head options
- Superior tension load performance
- Designed for use with impact drivers or cordless drills
Simpson Strong-Tie TNT18114TFC8 Applications
- Wood-to-concrete anchoring
- Wood-to-wood anchoring
- Electrical boxes and conduit mounting
- Light fixtures and window installations
- Handrails and thresholds
Simpson Strong-Tie TNT18114TFC8 Installation Overview
- Drill a hole using the specified diameter carbide drill bit.
- Position the fixture and insert the screw.
- Tighten using a drill and the Titen Turbo installation tool.
Simpson Strong-Tie TNT18114TFC8 Specifications
| Material | Carbon Steel |
| Finish | Blue Zinc |
| Diameter | 3/16″ |
| Length | 1-1/4″ |
| Drill Bit Size | 5/32″ |
| Drive Type | T25 Star Drive |
| Head Type | Flat Head |
NOTE: Designed for installation with an impact driver or cordless drill. Installation using the Titen Turbo Installation Tool is recommended. Matched-tolerance bit not required; use a standard ANSI drill bit for installation. Intended for use in dry interior environments only.
