Simpson Strong-Tie TBG1245S Strong-Drive (#12 x 1-3/4″) T30 Flat Head TB Wood-to-Steel Screw (Collated) (1000 Pack)
Simpson Strong-Tie TBG1245S Description
The Quik Drive TB Wood-to-Steel Collated Screw is designed for fastening wood to steel with a maximum thickness of 1/4 inch. It features a flat head with nibs for easy countersinking and a #4 drill point with wings for general duty applications.
Simpson Strong-Tie TBG1245S Includes
- (1000) #12 x 1-3/4 in. Quik Drive TB Wood-to-Steel Collated Screw
Simpson Strong-Tie TBG1245S Features
- Flat head with nibs for easy countersinking
- #3 square drive for secure fastening
- #4 drill point with wings for general duty applications
- Straight collation for efficient use
Simpson Strong-Tie TBG1245S Applications
- Fastening wood to steel with a maximum thickness of 1/4 inch
Simpson Strong-Tie TBG1245S Specifications
| Fastener Type | Quik Drive Collated Screw |
| Coating/Material | N2000 Mechanically Galvanized |
| Screw Size | #12 |
| Length | 1-3/4 in. |
| Head Diameter | 0.388 in. |
| Drive Type | #3 Square |
| Head Type | Flat Head |
| Thread Type | Tapping Threads |
| TPI | 14 |
| Max. Grip Length | 1.055 in. |
| Point Type | Drill Point with Wings |
| Point Size | 4 |
| Compatible Tools | Quik Drive PROHSD60, Quik Drive PROHSD60M |
| Packaging Qty. | 1000 |
NOTE: Use this product in dry, interior, and noncorrosive environments only.
