Simpson Strong-Tie SSWTPF12 Strong-Wall Steel Panel Anchor Bolt Template for 12″ Wall – (SSW12)
Simpson Strong-Tie SSWTPF12 Description
The Steel Anchor Bolt Template for 12″ Panel by Simpson Strong-Tie ensures accurate anchor bolt placement for Steel Strong-Wall shearwalls.
Simpson Strong-Tie SSWTPF12 Includes
- (1) Steel Anchor Bolt Template for 12″ Panel
Simpson Strong-Tie SSWTPF12 Features
- Accurately locates anchor bolts for Steel Strong-Wall shearwalls
- Templates can be used with various anchor bolt models
- Variety of templates to fit all application needs
Simpson Strong-Tie SSWTPF12 Applications
- Anchorage for standard application on concrete foundation
- Garage portal systems on concrete foundations
- First-story wood floor systems
- Balloon framing on concrete foundations
- Two-story stacked on concrete foundations
- Cold formed steel on concrete foundations
Simpson Strong-Tie SSWTPF12 Installation Overview
- Installation of Steel Strong-Wall anchor bolt templates varies by application
Simpson Strong-Tie SSWTPF12 Specifications
| Special Order | FALSE |
| Application | Anchor Bolt Templates |
| API Approval | Approved – Full |
NOTE: Templates are recommended and are required in some jurisdictions. Foundation design by designer. Templates are the same for 4″ or 6″ thick walls.
