Simpson Strong-Tie SL25300PFP1 (1/4″ x 3″) Sleeve-All Phillips Flat-Head Sleeve Anchor – Zinc-Plated (1 Piece)
Simpson Strong-Tie SL25300PFP1 Description
The Sleeve-All 1/4 in. x 3 in. Phillips Flat-Head Sleeve Anchor is a reliable mechanical anchor designed for solid base materials, offering optimal performance in structural applications.
Simpson Strong-Tie SL25300PFP1 Includes
- (1) Sleeve-All 1/4 in. x 3 in. Phillips Flat-Head Sleeve Anchor
Simpson Strong-Tie SL25300PFP1 Features
- Pre-assembled expanding anchor
- Optimal performance in structural applications
- Suitable for solid base materials
- Available in various head options
Simpson Strong-Tie SL25300PFP1 Applications
- Securing into concrete and brick
- Hollow and grouted CMU applications
- Structural anchoring in demanding environments
Simpson Strong-Tie SL25300PFP1 Installation Overview
- Drill a hole in the base material using a carbide drill bit of the same diameter as the anchor.
- Drill to the specified embedment depth and clean the hole using compressed air.
- Place the anchor in the fixture and drive it into the hole until tight.
- Tighten to the required installation torque.
Simpson Strong-Tie SL25300PFP1 Specifications
| Diameter | 1/4″ |
| Finish | Zinc Plated |
| Length | 3″ |
| Material | Carbon Steel |
| Drill bit size | 1/4″ |
| Head type | Phillips Flat head |
| Manufacturer name | Simpson Strong-Tie |
| Quantity | 1 |
NOTE: Oversized holes will make it difficult to set the anchor and will reduce the anchor’s load capacity.
