Simpson Strong-Tie SDCF22512-R50 Strong-Drive (0.590″ x 5-1/2″) T40 Yellow Zinc Timber-CF Screw, Flat Head w/ Nibs (50 Pack)
Simpson Strong-Tie SDCF22512-R50 Description
The Simpson Strong-Drive SDCF Timber-CF screw is a structural fastener designed for cross-laminated timber and mass timber construction, providing uncompromised strength and clean countersinking.
Simpson Strong-Tie SDCF22512-R50 Includes
- (50) 0.315 in. x 5-1/2 in. Yellow Zinc Timber-CF Screw
Simpson Strong-Tie SDCF22512-R50 Features
- Designed to be countersunk with head flush to wood surface
- Fully threaded to provide high withdrawal resistance
- Flat head with nibs helps countersink the screw for a flush finish
- Heavy-duty, fully-threaded shank provides strength, with superb withdrawal resistance
- Head stamp includes length in mm for inspection
- Interior grade yellow-zinc coating
- Deep 6-lobe recess for a secure drive
Simpson Strong-Tie SDCF22512-R50 Applications
- Beam reinforcement
- Wall-to-wall connections
- Floor-to-floor connections
- Support beams
- Butt joints
Simpson Strong-Tie SDCF22512-R50 Specifications
| Diameter | 0.315 in. |
| Finish | Yellow Zinc |
| Length | 5-1/2 in. |
| Material | Carbon Steel |
| Drive type | T40 Star Drive |
| Head diameter | 0.59 in. |
| Head type | Flat Head with Nibs |
| Point type | Half Point |
| Thread length | 5-1/8 in. |
| Quantity | 50 |
