Simpson Strong-Tie RSP4 (4-1/2 in.) Reversible Stud-Plate Tie G90 Galvanized
Simpson RSP4 Description
The RSP4 Reversible Stud-Plate Tie is designed to connect wood studs to double top plates or sill plates, featuring locating tabs for precise placement and embossments for enhanced strength.
Simpson RSP4 Includes
- (1) Reversible Stud-Plate Tie
Simpson RSP4 Features
- Versatile design for connecting wood studs to plates
- Locating tabs for precise placement
- Embossments for strengthened stud-plate connection
- Resists wind and seismic forces
- G90 Galvanized finish for durability
Simpson RSP4 Applications
- Wood-framed wall construction
- Securing studs to double top plates
- Securing studs to sill plates
- Enhancing structural integrity against wind and seismic forces
Simpson RSP4 Installation Overview
- Position the tie to align with the stud and plate.
- Secure the tie using the specified fasteners.
- Ensure proper placement using locating tabs.
- Verify the connection strength with embossments.
Simpson RSP4 Specifications
| Finish | G90 Galvanized |
| For Treated Lumber | No |
| Fasteners required | Stud: (4) 0.131 x 1 1/2 Plate: (4) 0.131 x 1 1/2 |
NOTE: Ensure the correct fasteners are installed in the correct position to achieve published load values.
