Simpson Strong-Tie PFDS26B (2×6) Galvanized Post-Frame Top-Flange Saddle Hanger
Simpson Strong-Tie PFDS26B Description
The PFDS26B is a galvanized post-frame saddle hanger designed for double 2×6 joists, offering superior load capacity and corrosion resistance for various framing applications.
Simpson Strong-Tie PFDS26B Includes
- (1) Galvanized Post-Frame Saddle Hanger for Double 2×6
Simpson Strong-Tie PFDS26B Features
- High-strength construction with heavy-gauge steel
- Corrosion-resistant G90 galvanized finish
- Top-flange saddle design for stable support
- Code-compliant engineering for secure connections
- Versatile application for wood and concrete beams
Simpson Strong-Tie PFDS26B Applications
- Post-frame buildings: Secure joist support in agricultural and storage structures
- Commercial and residential framing: Strong connections for decks and pavilions
Simpson Strong-Tie PFDS26B Installation Overview
- Attach joist to hanger using nails or screws
- Secure top flange to beam with structural nails or screws
- For concrete beams, use mechanical or adhesive anchors
Simpson Strong-Tie PFDS26B Specifications
| Finish | G90 Galvanized |
| Material | Carbon Steel |
| Fasteners required | SEE PRODUCT GUIDE DOCUMENT |
| For Treated Lumber | No |
| Height | 5-3/8″ |
| Joist size | 2″ X 6″ |
| Thickness | 20 Gauge |
| Width | 1-9/16″ |
