Simpson Strong-Tie PAB9-36 (1-1/8″ x 36″) High-Strength Pre-Assembled Anchor Bolt for Concrete Applications
Simpson Strong-Tie PAB9-36 Description
The Simpson Strong-Tie PAB9-36 is a high-strength, pre-assembled anchor bolt designed for concrete applications, offering durability and compliance with ASTM standards.
Simpson Strong-Tie PAB9-36 Includes
- (1) 1-1/8″ x 36″ Pre-Assembled Anchor Bolt
Simpson Strong-Tie PAB9-36 Features
- Available in diameters from 1/2″ to 1 1/4″ and lengths from 12″ to 36″
- Made from high-strength steel
- Head stamp includes No Equal sign, diameter designation, and “H” for high-strength rods
Simpson Strong-Tie PAB9-36 Applications
- Ideal for high-tension-load applications such as shearwalls and rod systems
- Suitable for multi-story high-wind constructions
Simpson Strong-Tie PAB9-36 Installation Overview
- Chase threads on HDG PABs to use standard nuts or couplers
- Use overtapped products in accordance with ASTM A563
Simpson Strong-Tie PAB9-36 Specifications
| Diameter | 1-1/8″ |
| Length | 36″ |
| Material | High-Strength Steel |
| Finish | Plain |
| Weight | 10.4 lb |
NOTE: Ensure threads are chased on HDG PABs to use standard nuts or couplers, or use overtapped products as per ASTM A563.
