Simpson Strong-Tie PAB8H-12 (1″ x 12″) High-Strength Pre-Assembled Anchor Bolt for Concrete Applications
Simpson Strong-Tie PAB8H-12 Description
The Simpson Strong-Tie PAB8H-12 is a high-strength steel pre-assembled anchor bolt designed for concrete applications, offering durability and reliability for high-tension-load scenarios.
Simpson Strong-Tie PAB8H-12 Includes
- (1) 1″ x 12″ High-Strength Steel Pre-Assembled Anchor Bolt
Simpson Strong-Tie PAB8H-12 Features
- Made from high-quality ASTM A449 steel
- Designed for high-tension-load applications
- Pre-assembled for convenience
- Available in various diameters and lengths
- Head stamp includes No Equal sign and diameter designation
Simpson Strong-Tie PAB8H-12 Applications
- Concrete anchoring for shearwalls
- Rod systems requiring high-tension loads
- Multi-story high-wind applications
Simpson Strong-Tie PAB8H-12 Installation Overview
- Chase threads on HDG PABs to use standard nuts or couplers
- Use overtapped products in accordance with ASTM A563
- Contact Simpson Strong-Tie for special orders
Simpson Strong-Tie PAB8H-12 Specifications
| Diameter | 1″ |
| Length | 12″ |
| Material | High-Strength Steel |
| Finish | Plain |
| Weight | 3.7 lb |
NOTE: Ensure threads are chased on HDG PABs to use standard nuts or couplers, or use overtapped products in accordance with ASTM A563.
