Simpson Strong-Tie PAB8-18 (5/8″ x 18″) Pre-Assembled Anchor Bolt for Concrete Construction
Simpson Strong-Tie PAB8-18 Description
The Simpson Strong-Tie PAB8-18 is a pre-assembled anchor bolt designed for concrete construction, offering durability and reliability.
Simpson Strong-Tie PAB8-18 Includes
- (1) Pre-Assembled Anchor Bolt 5/8″ x 18″
Simpson Strong-Tie PAB8-18 Features
- Available in diameters from 1/2″ to 1 1/4″ and lengths from 12″ to 36″
- Available in standard and high-strength steel
- Head stamp contains the No Equal sign, diameter designation and an “H” on high-strength rods
Simpson Strong-Tie PAB8-18 Applications
- Multi-Story High-Wind
Simpson Strong-Tie PAB8-18 Installation Overview
- On HDG PABs, chase the threads to use standard nuts or couplers or use overtapped products in accordance with ASTM A563
Simpson Strong-Tie PAB8-18 Specifications
| Material | Standard Steel — ASTM F1554 Grade 36, A36 or A307; Fu = 58 ksi |
| High-Strength Steel (up to 1″ dia.) | ASTM A449; Fu = 120 ksi |
| High-Strength Steel (1 1/8″ and 1 1/4″ dia.) | ASTM A193 B7 or F1554 Grade 105; Fu = 125 ksi |
| Finish | None or HDG |
