Simpson Strong-Tie LSSC4.25-R50 (4-1/4″ x 16-Gauge) Galvanized Steel-Stud Clip (50 Pack)
Simpson Strong-Tie LSSC4.25-R50 Description
Simpson LSSC connectors are versatile utility clips ideal for a variety of stud-to-stud and stud-to-structure applications in cold-formed steel construction.
Simpson Strong-Tie LSSC4.25-R50 Includes
- (50) Steel-Stud Clips
Simpson Strong-Tie LSSC4.25-R50 Features
- Prepunched holes reduce installation cost by eliminating predrilling
- Intuitive fastener hole positions ensure accurate clip installation
- Angle lengths accommodate either hard-side or soft-side attachment
- 4″ leg length enables soft-side connections for studs and joists with flanges up to 3″
- Suitable for u-channel bridging
Simpson Strong-Tie LSSC4.25-R50 Applications
- Curtain-Wall Construction
- Stud-to-stud and stud-to-structure connections in cold-formed steel construction
Simpson Strong-Tie LSSC4.25-R50 Installation Overview
- Use all specified fasteners/anchors
Simpson Strong-Tie LSSC4.25-R50 Specifications
| Material | 54 mil (50 ksi) |
| Finish | G90 Galvanized |
| Gauge | 16 |
| Dimensions | 2 1/4 x 4 in. |
| Length | 4 1/4 in. |
| Packaging Quantity | 50 |
NOTE: The correct fasteners installed in the correct position must be used to achieve published load values.
