Simpson Strong-Tie HHETA16 (12″) 12 Gauge Embedded Truss Anchor
Simpson Strong-Tie HHETA16 Description
The HHETA16 12″ Embedded Truss Anchor provides an engineered solution for securely attaching roof trusses to concrete and masonry walls, featuring staggered nail patterns for enhanced uplift resistance.
Simpson Strong-Tie HHETA16 Includes
- (10) 0.148″ x 1-1/2″ Fasteners
Simpson Strong-Tie HHETA16 Features
- Engineered design for secure truss attachment
- Staggered nail patterns for increased uplift resistance
- Compatible with concrete and masonry walls
- Includes specified fasteners for installation
Simpson Strong-Tie HHETA16 Applications
- Roof truss attachment to concrete walls
- Roof truss attachment to masonry walls
- Structural reinforcement in construction projects
Simpson Strong-Tie HHETA16 Installation Overview
- Embed anchor 4″ into a 6″ minimum concrete beam or 8″ nominal grouted block wall
- Use all specified fasteners included
- Ensure proper alignment and embedment depth
- Follow guidelines for mislocated truss anchors and shim design
- Avoid fastener installation where straps overlap in double embedded anchor setups
Simpson Strong-Tie HHETA16 Specifications
| Fasteners required | (10) 0.148″ x 1-1/2″ |
| For Treated Lumber | No |
| Height | 12″ |
| Manufacturer name | Simpson Strong-Tie |
NOTE: The correct fasteners installed in the correct position must be used to achieve published load values.
