Simpson Strong-Tie DCU234P316 Deck-Drive (#10 x 2-3/4″) T20 DCU SS Composite Screw, Type 316 (350 Pack)
Simpson Strong-Tie DCU234P316 Description
Simpson DCU composite screws are engineered to provide beautiful fastening results for all types of composite decking while also offering greater ease of installation, a clean finish, and superb corrosion resistance.
Simpson Strong-Tie DCU234P316 Includes
- (350) #10 x 2-3/4 in. DCU Composite Decking Screw
Simpson Strong-Tie DCU234P316 Features
- Tri-lobe thread design reduces damage to the composite board while driving
- Inverted upper threads clear excess material to ensure that the screw has a clean finish
- Unique cut point penetrates composite decking with ease for fast starts
- Cap head prevents mushrooming and material from rising up above the deck for a smoother, clean-looking installation
- Approved fastener by Trex for Trex composite decking
- Available collated for the Quik Drive system
- Compatible with color-matching DCU Screw Plugs
Simpson Strong-Tie DCU234P316 Applications
- Fastening composite decking boards
- Fastening roof sleeper assemblies
Simpson Strong-Tie DCU234P316 Specifications
| Diameter | #10 |
| Length | 2-3/4″ |
| Material | 316 Stainless Steel |
| Color | Unpainted |
| Drive type | T20 Star Drive |
| Head type | Cap Head |
| Manufacturer name | Simpson Strong-Tie |
| Quantity | 350 |
NOTE: The correct fasteners installed in the correct position must be used to achieve published load values.
