Simpson Strong-Tie CCOQ6-SDS2.5HDG (5-1/4″ or 5-1/2″) 7Ga Quick Install Column Cap Only – Hot-Dip Galvanized
Simpson Strong-Tie CCOQ6-SDS2.5HDG Description
The Simpson Strong-Tie CCOQ6-SDS2.5HDG Column Cap is a heavy-duty connector designed for 6x beams, featuring a hot-dip galvanized finish for enhanced durability.
Simpson Strong-Tie CCOQ6-SDS2.5HDG Includes
- (1) Column Cap
- (16) 1/4″ x 2 1/2″ Strong-Drive SDS Heavy-Duty Connector screws
Simpson Strong-Tie CCOQ6-SDS2.5HDG Features
- Hot-Dip Galvanized finish for corrosion resistance
- Designed for 6x beams
- Includes Strong-Drive SDS screws for quick installation
- Extended surface area for load distribution
- Strapless design for field welding to steel columns
Simpson Strong-Tie CCOQ6-SDS2.5HDG Applications
- Wood-to-wood column-to-beam connections
- Field welding to steel columns
- Construction projects requiring durable connectors
Simpson Strong-Tie CCOQ6-SDS2.5HDG Installation Overview
- Fasten with provided Strong-Drive SDS screws
- Use stainless-steel screws with stainless-steel connectors
- May be ordered for field welding to pipe or other columns
Simpson Strong-Tie CCOQ6-SDS2.5HDG Specifications
| Material | Steel |
| Finish | Hot Dip Galvanized |
| Beam size | 6x |
| Fasteners required | 1/4″ x 2 1/2″ Strong-Drive SDS Heavy-Duty Connector screws |
| Height | 7″ |
| Width | Beam 5-1/4″, 5-1/2″ |
| Thickness | 7 Gauge |
| Length | 11″ |
NOTE: The correct fasteners installed in the correct position must be used to achieve published load values.
