Simpson Strong-Tie CB46 (4″ x 6″) Galvanized Column Base
Simpson Strong-Tie CB46 Description
The Simpson CB46 4×6 Column Base enhances the strength and stability of your construction projects, connecting columns or posts to concrete foundations.
Simpson Strong-Tie CB46 Includes
- (1) CB46 Column Base
Simpson Strong-Tie CB46 Features
- Designed to be cast-in-place or wet-set into concrete
- Intended for use with 4×6 posts/columns
- Made from Heavy Gauge Steel
- Finished with G90 Galvanized coating
- Increased uplift resistance for wind or seismic loading
Simpson Strong-Tie CB46 Applications
- Connecting columns or posts to concrete foundations
- Providing structural support for construction projects
- Enhancing stability in wind or seismic conditions
Simpson Strong-Tie CB46 Installation Overview
- Prepare the concrete foundation for casting or wet-setting
- Position the column base flush with the concrete surface
- Secure the column base using specified bolts
- Ensure proper alignment and stability of the column or post
Simpson Strong-Tie CB46 Specifications
| Finish | G90 Galvanized |
| Material | Heavy Gauge Steel |
| Column size | 4X6 |
| Fasteners required | Bolts – (2) 5/8″ |
| For Treated Lumber | No |
NOTE: The correct fasteners installed in the correct position must be used to achieve published load values.
