Simpson Strong-Tie BPS 1/2-3 (3″ x 3″) Slotted Bearing Plate with 1/2″ Bolt Diameter
Simpson BPS 1/2-3 Description
The Simpson BPS 1/2-3 Slotted Bearing Plate is designed for wood-to-concrete applications, featuring a slotted hole for adjustability and compatibility with heavy-duty screw anchors.
Simpson BPS 1/2-3 Includes
- (1) Slotted Bearing Plate with 1/2″ Bolt Diameter
Simpson BPS 1/2-3 Features
- Eliminates the need for standard-cut washers when used with Titen HD heavy-duty screw anchors
- Slotted hole allows for adjustability
- May be ordered with a hot-dip galvanized (HDG) finish for higher corrosion resistance
Simpson BPS 1/2-3 Applications
- Wood-to-concrete fastening
- Structural reinforcement in construction projects
- Heavy-duty framing applications
Simpson BPS 1/2-3 Installation Overview
- Position edge of plate washer within 1/2″ of sheathed edge of sill plate for shearwall applications
- Tighten BPS to each anchor bolt with nut and standard cut-washer
- Washer not required when used with Titen HD heavy-duty screw anchors
Simpson BPS 1/2-3 Specifications
| Material | 3 Gauge |
| Finish | None or Hot Dip Galvanized |
| Bolt Diameter | 1/2″ |
| Width | 3″ |
| Length | 3″ |
| Thickness | 0.229″ |
NOTE: Standard cut-washer required with BPS slotted bearing plates. Washer not required when used with Titen HD heavy-duty screw anchors.
