Simpson Strong-Tie BP5/8SKTHDG Hot-Dip Galvanized Bearing Plate Kit for 5/8″ Anchor Bolts
Simpson Strong-Tie BP5/8SKTHDG Description
The Simpson Strong-Tie BP5/8SKTHDG is a hot-dip galvanized bearing plate kit designed for 5/8″ anchor bolts, providing a greater bearing surface and enhanced corrosion resistance.
Simpson Strong-Tie BP5/8SKTHDG Includes
- (50) Bearing Plates
- (XX) 1/4″ x 1 1/2″ Strong-Drive SDS Connector screws
Simpson Strong-Tie BP5/8SKTHDG Features
- Replaces standard cut-washers while providing a greater bearing surface
- Sized for most common anchor bolt sizes: 3/8″, 1/2″, 5/8″, 3/4″, 7/8″ and 1″
- May be ordered HDG for higher corrosion resistance
Simpson Strong-Tie BP5/8SKTHDG Applications
- Fastening wood to concrete or masonry
Simpson Strong-Tie BP5/8SKTHDG Installation Overview
- Position edge of plate washer within 1/2″ of sheathed edge of sill plate for shearwall applications.
- Use 1/4″ x 1 1/2″ Strong-Drive SDS Heavy-Duty Connector screws for lateral resistance when 5/8″-diameter sill holes are overdrilled.
- Tighten each anchor bolt with a nut and BP.
Simpson Strong-Tie BP5/8SKTHDG Specifications
| Bolt Diameter | 5/8″ |
| Gauge | 3 ga. |
| Thickness | 0.229″ |
| Width | 4″ |
| Length | 2″ |
| Coating/Material | Hot-Dip Galvanized |
| Packaging Quantity | 50 |
NOTE: Each kit includes 50 bearing plates and (XX) 1/4″ x 1 1/2″ Strong-Drive SDS Connector screws.
