Simpson Strong-Tie BP 5/8-3HDG (3 in. x 3 in.) Bearing Plate with 5/8″ Bolt – Hot-Dip Galvanized Finish
Simpson BP 5/8-3HDG Description
The Simpson BP 5/8-3HDG Bearing Plate is designed for reinforcing and stabilizing structural connections in wood and steel construction projects. Featuring a 5/8″ precision-cut hole and hot-dip galvanized finish, it ensures secure fastening and corrosion resistance.
Simpson BP 5/8-3HDG Includes
- (1) Bearing Plate with 5/8″ Bolt Diameter and Hot-Dip Galvanized Finish
Simpson BP 5/8-3HDG Features
- Heavy-Duty Construction: Built from 3 Gauge steel for superior strength and load support.
- Hot-Dip Galvanized Coating: Offers excellent corrosion resistance, perfect for outdoor and exposed conditions.
- 5/8″ Precision-Cut Hole: Ensures secure fastening with standard-sized bolts.
- Compact 3″ x 3″ Size: Provides flexibility for a wide range of projects and reinforcement needs.
- Versatile Applications: Ideal for wood and steel construction, heavy framing, and critical structural connections.
Simpson BP 5/8-3HDG Applications
- Wood and steel construction projects requiring reinforcement and stability.
- Heavy framing applications.
- Critical structural connections in commercial buildings, bridges, and other projects.
Simpson BP 5/8-3HDG Installation Overview
- Position edge of plate washer within 1/2″ of sheathed edge of sill plate for shearwall applications.
- Use standard cut-washer with BPS slotted bearing plates unless used with Titen HD heavy-duty screw anchors.
- Tighten BPS to each anchor bolt with nut and standard cut-washer.
Simpson BP 5/8-3HDG Specifications
| Finish | Hot-Dip Galvanized |
| Length | 3″ |
| Width | 3″ |
| Material | 3 Gauge Steel |
NOTE: Standard cut-washer required with BPS 1/2-3, BPS 5/8-3, BPS 3/4-3, BPS 1/2-6, BPS 5/8-6, and BPS 3/4-6 (not provided) per the 2012/2015/2018/2021 IRC and 2015/2021 SDPWS.
