Simpson Strong-Tie BP 1 (3-1/2″ x 3-1/2″) Bearing Plate with 1″ Bolt Diameter
Simpson Strong-Tie BP 1 Description
The BP 1 Bearing Plate is designed for structural reinforcement, providing a secure and stable connection in wood and steel construction projects.
Simpson Strong-Tie BP 1 Includes
- (1) BP 1 Bearing Plate
Simpson Strong-Tie BP 1 Features
- Replaces standard cut-washers while providing a greater bearing surface
- Sized for most common anchor bolt sizes: 3/8″, 1/2″, 5/8″, 3/4″, 7/8″ and 1″
- May be ordered HDG for higher corrosion resistance
- Heavy-duty construction with 3/8″ thick steel
- Compact 3.5″ x 3.5″ size for versatile applications
Simpson Strong-Tie BP 1 Applications
- Wood-to-concrete or masonry fastening
- Reinforcing and stabilizing structural connections in wood and steel construction
- Ideal for heavy framing and critical structural connections
Simpson Strong-Tie BP 1 Installation Overview
- Position edge of plate washer within 1/2″ of sheathed edge of sill plate for shearwall applications
- Tighten each anchor bolt with a nut and BP
- No additional standard cut-washer required
Simpson Strong-Tie BP 1 Specifications
| Bolt Diameter | 1″ |
| Thickness | 3/8″ |
| Width | 3-1/2″ |
| Length | 3-1/2″ |
