Simpson Strong-Tie AC6 (5-1/2″ x 8-1/2″) 18ga AC Galvanized Adjustable Post Cap
Simpson Strong-Tie AC6 Description
The AC6 Adjustable Post Cap is designed to securely attach the top of posts to beams, featuring a G90 galvanized finish for enhanced corrosion resistance.
Simpson Strong-Tie AC6 Includes
- (1) Adjustable Post Cap for 6X Beam Zinc Galvanized
Simpson Strong-Tie AC6 Features
- Adjustable design for versatile post-to-beam connections
- G90 galvanized finish for corrosion resistance
- Compatible with specified nails or Strong-Drive SD connector screws
- Suitable for use with treated lumber
Simpson Strong-Tie AC6 Applications
- Post-to-beam connections in construction projects
- Structural support for decks and patios
- General framing applications requiring secure post attachment
Simpson Strong-Tie AC6 Installation Overview
- Use all specified fasteners
- Ensure fasteners meet ASTM A153 specifications
- Install fasteners in the correct position to achieve published load values
Simpson Strong-Tie AC6 Specifications
| Finish | Zinc Galvanized |
| Length | 8-1/2″ |
| For Treated Lumber | Yes |
| Post size | 6X |
| Thickness | 18 Gauge |
| Width | 5-1/2″ |
NOTE: The correct fasteners installed in the correct position must be used to achieve published load values.
