Proto J10045 1″ DRIVE IMPACT SOCKET 2-13/16″ – 6 POINT
INCLUDES:
• (1) 1″ DRIVE IMPACT SOCKET 2-13/16″ – 6 POINT
FEATURES:
• Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
• The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
• The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
• The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
SPECIFICATIONS:
• SIZE: 2-13/16”
• NUT END OUTSIDE DIAMETER: 4″
• DRIVE END OUTSIDE DIAMETER: 2-3/8″
• NUT DEPTH: 1-7/8”
• BOLT CLEARANCE DEPTH: 2-3/64″
• OVERALL LENGTH: 3-13/16″
• WEIGHT: 5.99 lbs
• CRUSH RETAINING RING: JRR10040
• DRIVE SIZE: 1″
• POINT SIZE: 6
• FINISH: Black Oxide
• LENGTH TYPE: Standard
• UNIT OF MEASURE: Fractional
