Klein 93CPLG Compact Green Planar Laser Level
INCLUDES:
• (1) Laser Level
• (1) Mounting Clamp
• (1) Soft Carrying Case
• (1) Instruction Manual
FEATURES:
• Rechargeable Self-Leveling Green Laser Level has 3 easy-to-read bright green 360-Degree laser planes with a working range of 100 feet (30.5 m); up to 2 times brighter than regular red beams
• Compact and lightweight design with lasers in 3 planes is easy to use in tight areas and to store when not in use
• High precision laser project clean lines with accuracy of 3/16-Inch at 30 feet (9.1 m); auto out-of-level detection flashes lasers when no longer level
• Tilt mode allows for the laser level to be turned on while the pendulum is locked for use at different angles
• Magnetic mounting bracket screws into integrated 1/4-Inch tripod mount
• More than 6-Hour runtime provides lasers power for all day use
• Durable overmold design that is IP54 rated protects the laser level from water and dust
SPECIFICATIONS:
• Type: Self-Leveling Laser Level
• Application: Self-Leveling Laser Alignment Instrument that Delivers Horizontal and/or Vertical Cross Lines
• Special Features: Manual Tilt Mode, Out of Angle Notification, Battery Fuel Gauge
• Material: PC+ABS+TPE
• Batteries: Lithium-Ion
• Laser Wavelength: 508-525 nm
• Laser Safety: 21 CFR 1040.10 and 1040.11 Except for Conformance with IEC 60825-1 Ed. 3., as Described in Laser Notice No. 56, Dated May 8, 2019
• Number of Beams: 3
• Laser Color: Green
• Plumb Laser: No
• Indoor Range: 100′ (30.5 m)
• Outdoor Range: 100′ (30.5 m)
• Maximum Distance: 100′ (30.5 m)
• Display: No
• Accuracy: 33′ (10m)
• Pulse Mode: No
• Receiver: No
The Klein Tools’ Compact Green Planar Laser Level is a high-performance laser leveling and alignment tool for professionals. Clear, bright green 360-Degree lines in the X-, Y- and Z-planes project from this level. Equipped with an integrated magnetic mount and 1/4-20 tripod mounting threads, Klein’s self-leveling laser level enables a multitude of alignment and layout applications. This product is classified as a Class II laser product according to IEC/EN 60825-1:2014, (Power ?1mW @ 508-530nm).
