Jet JT9-690115 JTM-4VS Mill Newall DP700 DRO X/Y-Axis Pwrfd Air Pwr Drawbar
Jet 690115 Description
Constructed using the Meehanite® casting process, JET Variable Speed Milling Machines provide consistent and reliable operation. Precision bored and honed milling heads ensure quality cuts, and the three-stage power downfeed with automatic stop makes the JET Variable Speed Milling Machines easy to use. Available in single or three phase power configurations, the JET JTM-4VS Series mills are backed by the industry leading two year full service and parts warranty
Jet 690115 Includes
- (1) JTM-4VS Mill with Newall DP700 DRO X and Y-Axis Powerfeeds & Air Power Drawbar
Jet 690115 Features
- Certified Meehanite® Castings
- Precision bored and honed milling head
- Large diameter quill is chromed
- High precision Class 7 spindle bearings
- Chrome plated motor shaft with lower bearing support
- Spindle head is internally cooled
- Heavy duty splined motor drive
- One piece quill pinion and shaft
- Three stage power downfeed with automatic stop
- Heavy duty spindle brake
Jet 690115 Specifications
| Style (Type) | Variable Speed R8 |
| Digital Readout | Newall DP700 |
| Number of Axis | 2 |
| Powerfeed | X and Y-Axis |
| Spindle Taper (In. x TPI) | R-8 |
| Table Size (L x W) (In.) | 9 x 49 |
| Quill Diameter (In.) | 3-3/8 |
| Number of Spindle Speeds | Variable |
| Range of Spindle Speeds (RPM) | 60 – 4,200 |
| Quill Down Feed Rates (IPR) | Quill Down Feed Rates (IPR) |
| Spindle Travel (In.) | 5 |
| Head Movement (Deg.) | 90° R & L, 45° F & B |
| Max Distance Spindle to Table (In.) | 17-1/2 |
| Distance Spindle to Column (Max.) (In.) | 19 |
| Distance Spindle to Column (Min.) (In.) | 4-1/2 |
| Collet Capacity | 1/8 – 7/8 |
| Table Longitudinal Travel (In.) | 34 |
| Table Longitudinal Travel with Powerfeed (In.) | 28-3/4 |
| Table Cross Travel (In.) | 12 |
| T-Slots Number and Size (In.) | 3 and 5/8 |
