Jet JT9-424460 HVBS-8-DMW Dual Miter Portable Bandsaw, 3/4HP
Jet 424460 Description
The JET Dual-Mitering band saw offers versatility and ease. The unique head design miters both left and right, allowing for quick angle cuts. Add to the convenience with easy conversion from a horizontal to vertical position, and wheels for moving around the shop floor.
Jet 424460 Features
- Built in, self propelled blade brush prevents chip build up in blade guides
- Head pressure controlled by a hydraulic cylinder
- Power switch with safety key prevents accidental start up
- CSA/CUS: Following strict guidelines and electrical requirements, this JET saw is CSA/CUS certifield
- Blade is fully guarded for Operator safety
- Automatic shut off switch stops the sawing process
- Hydraulic downfeed control is easily adjusted enabling feed rates to evolve with variable types of materials
- Head dual miters both left & right for quick angle cuts
- Protractor for fast and accurate angle cutting
Jet 424460 Specifications
| Blade Size (In.) | 3/4 x 0.035 x 102.9 |
| Blade Speed (SFPM) | 64, 132, 247 |
| Blade Wheel Diameter (In.) | 8-13/16 |
| Cutting Capacity (W x D) (In.) | 12 x 8 |
| Head Movement (Deg.) | +/- 45 |
| Motor (HP) | 3/4 HP, 115V, 1-Ph |
| Rectangle at 45 Degrees (In.) | 7 x 5-1/2 |
| Rectangle at 90 Degrees (In.) | 7 x 8 |
| Round at 45 Degrees (In.) | 6 |
| Round at 90 Degrees (In.) | 8 |
| Weight (Lbs.) | 500 |
| Overall Dimensions (L x W x H) (In.) | 24 x 54.7 x 43.8 |
| Prewired Voltage (V.) | 115V |
| Maximum Vise Opening (In.) | 8-1/4 |
| Table Height (In.) | 27-5/16 |
| Vertical Cutting Capacity | 12 x 8 |
