Freud 66-100 1/4″ (Dia.) Bevel Trim Bit
Freud 66-100 Description
The 41 Series Bits provide a range of bevels from 8 degrees to 45 degrees and feature a ball bearing guide.
Freud 66-100 Features
- The 66-100 solid carbide bit creates a 7-degree bevel and includes a self-piloting feature that eliminates the expense and upkeep of a ball bearing assembly.
- Cuts all plastic laminates.
- Use on Hand-held routers, table-mounted portable routers, and laminate trimmers for trimming plastic laminate.
Freud 66-100 Specifications
| Overall Diameter | 1/4″ |
| Bearing Diameter | 3/16″ |
| Carbide Height | 1/4″ |
| Angle (d) | 7° |
| Shank Diameter | 1/4″ |
| Overall Length | 1-1/2″ |
