Fluke VR1710 Single Phase Power Quality Recorder/Voltage Recorder
Fluke 3030923 Description
The Fluke VR1710 Power Quality Recorder, is a single-phase, plug-in voltage quality recorder that offers an extremely easy-to-use solution for detecting and recording power quality problems, allowing for immediate action and less downtime. The VR1710 single phase recorder satisfies the needs of maintenance and facilities management personnel in industrial, utilities, and large service organizations where reliable power quality is essential to the operation of the business. Power quality parameters including RMS average, transients, flicker, and harmonics up to the 32nd are recorded using a user-selected average period from 1 seconds to 20 minutes.
Fluke 3030923 Includes
- (1) Plug-in Fluke VR1710
- (1) USB cable
- (1) PowerLog software CD
- (1) Set Universal power cord adapters
Fluke 3030923 Features
- Single-phase, plug-in voltage quality recorder for detecting and recording power quality problems
- Records voltage trends, dropouts, and power quality to pinpoint the root cause
- Plugs directly into the mains power socket to capture data
- Presents a clear graphical summary of data and a quick overview of key power quality parameters
Fluke 3030923 Specifications
| Operating voltage | 70 V to 280 V |
| Min/Max/Avg RMS value | Resolution 0.125 V |
| Number of events | 175000 |
| Dips/interruptions | Yes |
| Time resolution | 5 ms |
| Voltage resolution | 0.125 V |
| Over-voltages | Yes |
| Frequency | Yes |
| Harmonics measurement | EN 61000-4-7 (up to 32nd) |
