Fluke 85RF-II 500 MHZ High Frequency Probe
Fluke 4094105 Description
The 85RF High Frequency Probe is designed to convert a DC voltmeter with a input impedance of 10M ohms into a high frequency (100kHz to 500Mhz) RF voltmeter.
Fluke 4094105 Includes
- (1) Fluke 85RF-II 500 MHZ High Frequency Probe
Fluke 4094105 Features
- High frequency probe is designed to convert a DC voltmeter with a input impedance of 10 megaohms into a high frequency (100kHz to 500 MHz) RF voltmeter
- Conversion from AC to DC is accomplished on a one-to-one basis includes a range of 0.25 to 30V rms
- The probe’s DC output is calibrated to be equivalent to the rms value of a sine wave input
- 0.25 to 30V rms voltage range
- 30V RMS, 200V DC maximum input voltage
Fluke 4094105 Specifications
| Voltage range | 0.25 to 30 Vrms |
| Maximum input voltage | 30 Vrms, 200 VDC |
| AC to DC ratio | 0.0423611111111111 |
