Condux 08773502 Aps75 With Compressor, Hydraulic Arm & Jacks
Condux 08773502 Description
The Condux APS75 Hydraulic Underground Cable Puller with Air Compressor provides up to 7,500 lbs of continuous pulling power to tackle some of the toughest pulling applications. This unit comes complete with a 185 CFM @ 100 PSI Air Compressor.
Designed for installing underground cable, the APS75 is completely self-contained and transports easily from jobsite to jobsite.
Industry leading features like antitwist rope, digital monitoring, rotating pulling arm and wired remote control make the APS75 the most advanced pulling system on the market today.
The APS75 is precision manufactured to the highest standards. Each puller is backed with years of underground cable pulling experience and a commitment to quality customer service.
Condux 08773502 Includes
- (1) Air Compressor Unit
Condux 08773502 Features
- Straightforward Operator Controls allow for a very short training period
- DOT certified Trailer
- USB connection to record & download pulling operations
- Rotating arm pivots 15 degrees in either direction
- Easy access diesel engine for maintenance
- Hydraulic tool circuit to operate additional tools
- Comes with standard 2600ft of antitwist rope
- All moving parts are housed safely
- Electric brakes
- Numerous adjustable supports for optimum stability
Condux 08773502 Specifications
| Company | Sullair |
| Make | KUB1803 |
| Efficiency | Tier 4 Final |
| HP | 49HP |
| Actual Delivery – CFM (m3/min) Pressure | 185 (5.2) |
| Range – psig (bar) | 80 (5.5) |
| Working Weight – lbs (kg) | 1950 (845) |
| Length x Width x Height – in (mm) | 79.3 (789 x 40.7 (1034) x 47.8 (1214) |
| Tank | 27 Gal |
