Condux 08773001 The Blue Ox Cable Puller Without Compressor
Condux 08773001 Includes
- (1) Cable Puller without Compressor
Condux 08773001 Features
- Hydraulic boom arm extension
- Adjustable outriggers
- Easy to access maintenance components
- Traffic cone holder
- Advantages: Wireless remote provides maximum flexibility for operator
- Easy Set-Up
- Rugged design to withstand harshest conditions
- Easy layout for maintenance and service
- Hydraulically controlled arm and outriggers
- Superior factory service and support
- Instructional video and service manual provided
- Full on-site training, if necessary
Condux 08773001 Specifications
| Maximum Line Pull (lbs) | 8,500 |
| Maximum Speed (fpm) | 175 |
| Engine Type | Diesel, Tier 4 Final |
| Horsepower | 49 |
| Electrical System | 12 volt |
| Fuel Tank (g) | 18 |
| Dimensions | 8.4 inch diameter with 7 grooves |
| Antitwist Rope | 3/8” x 3000’ |
| Tool Circuit | 6.5 gpm @ 2400 psi |
| Width | 94 inches |
| Height | 98 inches |
| Length | 175 inches |
| Weight | 9,000 Pounds |
| Axle | Single Combining years of experience, field research and end user feedback, the Condux Blue Ox Cable Puller has been designed to excel in the most demanding utility applications. Featuring a heavy duty steel frame and hydraulically controlled boom and outriggers, The Ox does not require the arm to be supported during pulling operations. The extendable – up to 90” – steel boom arm boasts 150° of lateral adjustment, providing easy access in even the most confined areas. |
