3M 41717 Scotch 130C 3/4″x 30′ Linerless Rubber Splicing Tape
3M 40679 Includes
- (1) 3/4″ x 30′ Scotch Linerless Rubber Slicing Tape
3M 40679 Features
- This is a highly conformable, linerless Ethylene Propylene Rubber (EPR), high-voltage insulating tape that provides excellent thermal dissipation of splice heat
3M 40679 Specifications
| Adhesive Material: | Rubber Resin |
| Agency Approvals: | ASTM D-4388 Type 1, 2 & 3 HH-I-3825B |
| Backing Material: | Ethlylene Propylene Rubber |
| China RoHS – Below MCV: | Yes |
| Dielectric Strength (V/mil): | 750 V/mil |
| Emergency Overload Temperature Range: | 130 Degrees Celsius |
| EU RoHS Compliant: | Yes |
| Length: | 30 Linear Foot |
| Maximum Operating Temperature (Celsius): | 90 Degree Celsius |
| Operating Temperature Range: | -18 to 90 Degree Celsius |
| Operating Temperature Range (Fahrenheit): | 0 to 194 Degrees Fahrenheit |
| Product Family: | Scotch® Linerless Rubber Splicing Tape 130C |
| Tape Color: | Black |
| Tape Grade: | Premium |
| Tape Length: | 30 Linear Foot |
| Tape Type: | Rubber Insulating and Splicing |
| Tape Width: | 0.75 |
| Tensile Strength: | 250 Pound-Force Per Square Inch |
| Tensile Strength lb/in (N/100mm): | 7.5 (131) |
| Thickness: | 30 Milli-Inch (mil) |
| Width: | .75 Inch |
